  • Product introduction
       MIFARE Plus has including "advanced encryption standard (AES)" encryption technology, multiple security and also can help clients upgrade from the current MIFARE Classic deployment conveniently. Meanwhile it is compatible with S70 & S50 cards, the security to be higher.We can offer PVC blank card,printing card,paper-sticker tag,Key chain,TOKEN and thin & thick cards of various specifications according to ISO14443A.The applications contain Door-control system,Checking-in system,Identification system,Physical distribution system,Automation system and various member-cards such as: meal-selling,subway,public transportation,club and so on. And also it contains electronic consumption,electronic ticket,animal identification,target tracking,laundry management and various payment systems.
  • Qualifications
  • Chip:NXP MF1SPLUSx0y1
  • Storage capacity:2K/4K Bytes
  • Working frequency:13.56 MHz
  • Communication rate:106Kbps ~ 848Kbps
  • Operating distance:0 ~ 100mm
  • Operating time:1 ~ 5ms
  • Operating temperature:-20 ~ 55 ℃ (-68°F ~ +131°F)
  • EEPROM:>100,000 times
  • Data retention:>10 years
  • Dimension:ISO standard card 85.6x54x0.82
  • Packaging materials:PVC,PET,PETG,0.13mm copper wire
  • Encapsulation technology:Ultrasonic automatic plant line / Automatic touch welding
  • RF standard:ISO14443A
  • Available for size:85.6×54,83×20,+158×40,50×50,45×45,45×28,44×20,38×38,35×30
  •
