Model NO. |
MR810UA |
MR810UC |
MR810UG |
MR810UH |
Interface |
USB PC/SC |
MCU |
ARM7 NXP LPC2368 at 60MHz, 512KB FLASH + 64KB RAM |
PCD |
RC500 |
RC531 |
RC400 |
RC632 |
SAM card slot |
2slots, supported 9600, 19200, 38400, 55800, 57600, 115200, 230400bps |
Date storage |
4096K bytes, 512 bytes/block |
Display |
one the tri-color LED |
Buzzer |
yes |
RF standard |
ISO14443A |
|
ISO15693 |
ISO14443A |
ISO14443B |
ISO15693s |
|
Reading distance |
100mm(MIFARE typical distance) |
PICC |
MIFARE 1K |
MIFARE 4K |
FM11RF08 |
Ultralight |
Ultralight C |
MIFARE Mini |
DESfire |
MIFARE Plus |
MIFARE ProX |
T=CL TYPE A |
|
ISO7816 T=0 |
ISO7816 T=1 |
|
MIFARE 1K |
MIFARE 4K |
FM11RF08 |
Ultralight |
Ultralight C |
MIFARE Mini |
DESfire |
MIFARE Plus |
MIFARE ProX |
T=CL TYPE A |
|
SR176 |
SRI512 |
SRI1K |
SRI2K |
SRI4K |
SRIX4K |
AT88RF020 |
T=CL TYPE B |
|
ISO7816 T=0 |
ISO7816 T=1 |
|
NXP I.CODE SLI |
TI Tag_it HF-I |
ST LRI |
|
ISO7816 T=0 |
ISO7816 T=1 |
|
MIFARE 1K |
MIFARE 4K |
FM11RF08 |
Ultralight |
Ultralight C |
MIFARE Mini |
DESfire |
MIFARE Plus |
MIFARE ProX |
T=CL TYPE A |
|
SR176 |
SRI512 |
SRI1K |
SRI2K |
SRI4K |
SRIX4K |
AT88RF020 |
T=CL TYPE B |
|
NXP I.CODE SLI |
TI Tag_it HF-I |
ST LRI |
ST LRI |
|
ISO7816 T=0 |
ISO7816 T=1 |
|
|
