JMY370
JMY370 series are the popular type access card reader. It can be input information with the keyboard. The way of installation is 86 electrician-boxes. The interface is RS485 & Wiegand. And there are LED status indicator and buzzer in the JMY370. So these are of sound and light show for reading-card status. You can set the function and parameters easily under cooperation with JMY30x series access controller. The way of opening door can be of code + card. And also you can enjoy from the intelligent control.
-
Qualifications
- • Reading card frequency: 13.56MHz
- • Operating distance: 0 ~ 100mm
- • Communication rate: 9600bps ~ 115200bps
- • RF standard: ISO14443A & ISO14443B & ISO15693
- • The number of Key: 12
- • Status indicator: LED & Buzzer
- • Interface: RS485, Wiegand, UART(TTL)
- • Door opening method: Keyboard + IC Card + Bluetooth
- • Operating temperature: -20 ~ +70 ℃ (-68 ~ 158°F)
- • Power supply: DC 8~15V
|
|
|
|
|
